RuffStuff Y-Link Steering Assembly for GM 1-Ton TRE Applications

Description

This is your not so basic steering setup that mocks the factory setup with easier adjustment & much stronger tubing. The kit can be used with stock steering position on the knuckle or High Steer arms. The taper it is the standard GM 1 ton.
The adjustment is easier because we add Hex Head TRE weld bungs so a crescent wrench is your adjustment tool, not a pipe wrench, which will scar the tube and if too deep, cause a major stress riser. Not to mention what it does to the paint…
These are stronger than stock because we use 1.5″ X .25″ Wall DOM tubing and the TRE’s are made for a 1 ton rig and much larger than stock.
You will receive:

• 2 – 54″ of 1.5″ X .25″ wall DOM tubing
• 2 RH – 7/8″ Hex Head Weld Bungs, 18TPI for Tie Rod Ends
• 2 LH – 7/8″ Hex Head Weld Bungs, 18TPI for Tie Rod Ends
• 2 RH – 7/8″ Jam Nuts, 18TPI for Tie Rod Ends
• 2 LH – 7/8″ Jam Nuts, 18TPI for Tie Rod Ends
• 4 – Tie Rod Ends, 1 for the Y Link, 2 for the Tie Rod, & 1 High Angle TRE for the pitman arm

We supply more DOM than you need because it is way too easy to make a mistake in your calculations and you can always cut tube, growing it back is the hard part!
